SPECIFICATIONS

Advantage: Modern Design

Certificate: CE certification/ISO Certification

Certification: CE

Countertop: Phenolic Resin/Epoxy Resin/Ceramic/Granite/Marble/Stainless Steel

Feature: Aseptic

Function: Chemistry Laboratory

High-concerned chemical: None

Material: Cold-roll steel sheet

Name: lab Furniture/Lab Bench

Origin: Mainland China

Product name: All Steel Island Floor-Mounted Lab Work Bench

Standard accessories: Water tap/PP sink/Electrical Outlets

Structure: Floor Mounted

application: Hospital, School, Workshop, Laboratory, Institute, Plant, Industrial

design style: Modern

general use: Commercial Furniture

mail packing: N

material: Metal

metal type: Steel

model number: LB-FM-05

place of origin: Guangdong, China

type: Laboratory Furniture

The Product Is Customized, and The Price Is Based on The Packaging Size and Weight. Please Contact Customer Service for Consultation and Additional Discounts.



Countertops

(1) Phenolic Resin countertop: 12.7mm (Edge banding and Thicken to 25.4mm)/16mm thickness

(2) Epoxy Resin countertop: 16/19/20/25mm thickness

(3) Ceramic countertop: 20mm thickness

(4) Trespa countertop: 13/16/19/20/25mm thickness

(5) Granite/Marble countertop: 20mm thickness

Cabinet&Accessories

(1) Cabinet: 1.0mm full-thickness high-quality cold-roll steel sheet is used as a whole; the steel surface is treated, phosphating and other processes, and then electrostatic powder coated with epoxy resin, cured at 220°C high temperature. and the surface is smooth, with a thickness of up to 1.15mm~1.2mm. The cabinet door is double-layered inside and outside, filled with sound insulation material. (2) Connecting rod: The whole adopts 40*60*1.5mm thick high-quality cold-rolled rectangle tube, the steel surface is treated, phosphating and other processes, and then electrostatic powder coated with epoxy resin, cured at 220°C high temperature, and the surface is smooth. (3) Handle: Non-welded linear handle/C-shaped handle/Insertion Aluminum alloy handle. (4) Rail: DTC 16-inch three-section silent rail. (5) Hinge: DTC 105°/175° buffer hinge/stainless steel hinge. (6) Footing: Use laboratory-specific adjustable feet with an adjustment range of ≥35mm, strong bearing capacity, the balance of the Lab bench can be adjusted.y

Product	Dimensions  (Length*Depth*Height)
Floor Mounted Wall Bench	L*750*850mm/Customize (Lx2.46'x2.78'/Customize)
Floor Mounted Island Bench	L*1500*850mm/Customize (Lx4.92'x2.78'/Customize)
Floor Mounted Corner Bench	1000*1000*850mm/Customize (Lx3.28'x3.28'/Customize)
